18K BAR7 SERIES - COOLING ONLY R454B CONDENSING UNIT - UP TO 15.2 SEER2

SKU: BAR7-18-15

PRODUCT TYPE: Condensing Units

Product variants

Quantity

Click Here to View Product Catalog

View full details

Refrigerant Type: R454B

Unit Size - Inches (W x D x H): 23-5/8×23-5/8×24-15/16

Voltage: 208-230V

Air Flow - CFM (Hi / Mi / Lo): 3230

Tonnage: 1.50

dB(A) Noise Level (Hi / Mi / Lo): 65

SEER2: Up to 15.2

EER: Up to 12

Operating Mode: Cooling Only

Heat Capacity (BTU): Cooling Only

Cooling Capacity (BTU): 17800

Placement: Outdoor Condensing Unit

Outdoor Unit Net/Gross Weight (lbs.): 117/123

Features

- Environmentally friendly R454B refrigerant with a low Global Warming Potential value.
- Compressor designed for energy efficiency.
- Features thermal overload protection.
- Service valves with sweat connections and convenient gauge ports.
- Includes factory-installed high-pressure switch.
- AHRI certified and ETL listed.
- Includes a filter drier.
- The compact design enables easy installation, clearance, durability, and maneuverability.
- Features a powder-painted galvanized steel cabinet chassis.
- Protective steel louvered coil guard and a steel wire axial fan guard.
- An ECM fan motor paired with a uniquely designed fan blade ensures smooth airflow and quieter operation.
