SOUTHWIRE

STRANDED COPPER SHIELDED RISER RATED CMR/CMG/CL3R/FPLR PVC 3/C 18 AWG 300V CABLE - 1000' ROLL

STRANDED COPPER SHIELDED RISER RATED CMR/CMG/CL3R/FPLR PVC 3/C 18 AWG 300V CABLE - 1000' ROLL

SKU: R40003-1A

PRODUCT TYPE: Wire

Expedited Shipping

View full details

Features & Specifications

Southwire's general purpose, low voltage power limited product is ideal for remote control, signaling and power limited circuits. Applications can include security, sound and audio, public address, intercom, alarm and access control circuits. Product is 300V and Riser rated.

Stock # R40003-1A
No. of Conductors 3
Size (AWG or kcmil) 18 AWG
No. of Strands 7
Nom. OD (mils) 171
Nominal Total Weight (lbs/1000') 23

Standards & References
UL 444 CMR, NEC article 800
UL 1424 FPLR, NEC article 760
UL 13 CL3R, NEC article 725
Flame Test UL 1666 Vertical Riser / CSA FT4 (UL 1581)
CSA C22.2 CMG by C(UL)
RoHS-2 (European Directive 2011/65/EU )

Construction
Conductors: 18 AWG 7/.0150 BC, 3 CONDUCTORS TWISTED
Insulation: PVC, COLORS: BLACK, RED, WHITE
Shield/Drain: SHIELDED
Jacket: PVC
