• Precision superheat control optimized for R-410 A systems
• Enhanced power element design offers extended valve life
• Stainless steel power element eliminates corrosion and prevents valve failure
• Laser etched identification markings for permanent legibility
• Hermetic, leak-free construction of all joints
• Compact size allows installation in limited spaces
• Bi-directional capability allows one valve to control the superheat in both cooling and heating modes for close-coupled or packaged heat pump applications
• Balanced port construction compensates for changes in operating pressures due to varying ambients, gas defrost, heat reclaim, or widely varying evaporator loads
• External equalizer is standard
• Screens on ODF inlet connections
Refrigerant Code - Z (R-410A)
Charge Code - AA (Wide Range)
Capacity (Nominal) - 2 Tons
Inlet Connection Size - 3/8” ODF
Outlet Connection Size - 1/2” ODF
Adjustable Superheat - Yes
Equalizer - External (1/4” ODF)
Length - 5 Ft. Capillary
Bleed - No
Check Valve - Yes
Body Design - A (Adjustable Superheat, with Check, Straight Thru)
Maximum Working Pressure - 700 psig
R-410A Operating Range - (R-410A) -20°F to +50°F
Approvals - UR/CUR File Number SA5312
