ELECTRONIC SINGLE STAGE - OPEN/CLOSE ON RISE, SPDT, 120/240VAC
ELECTRONIC SINGLE STAGE - OPEN/CLOSE ON RISE, SPDT, 120/240VAC
SKU: A421ABC-02C
PRODUCT TYPE: Temperature Controllers
Features & Specifications
Features & Specifications
Switch Action: Open/Close on Rise
Voltage: 120/240VAC
Sensor Type: A99
Differential: 1 Degrees to 30 Degrees F
Display Type: LCD
Number of Relay Inputs: 1
Switch Type: SPDT
Color: Gray
Width: 2 3/8 in
Height: 5 in
Full Load Amps @ 240VAC: 8 A
Control Range: -40 Degrees to 212 Degrees F
Display Color: Black/White
Depth: 2 3/8 in
For Use With: Suitable for Temperature Control in Heating, Cooling Applications
Number of Relay Outputs: 1
Item: Electronic Temperature Control
Standards: UL, C-UL listed
Features: Removable Sensor with Screw Terminals and 6-1/2 ft Lead, Keypad Lock Out, Sensor Failure, Adjustable Anti Short Cycle Delay
Includes: (1) Mfr. No: A99BB-200C Temperature Sensor with 6 ft. 7-1/5 in. (2.0 m) Cable
Thermostat Switch Type: SPDT
Voltage Range: 120/240V AC
Enclosure Type: NEMA 1
Full Load Amps @ 120VAC: 16 A
Display Size: 1.5 x .5 sq in
Sensing Bulb Dia.: 1/4 in
Agency Compliance: C-UL listed, UL
Sensing Bulb Length: 2 in
